Installation 19
iina74e 02.fm technical handbook(1408)
For transportation fixing the screws are tightened to the chassis plate. For operation
of the UL5000 the screws should be loosened.
To loosen the screws first loosen the counter nut that is accessible from underneath:
Loosen the screws approximately 10 mm above the chassis plate anf tighten then
the counter nuts again:
Fig. 2-1
Fig. 2-2
