240
Chapter 7
Hex Code Printout
*
COAX INTERFACE
HEX PRINT MODE
Or
HEX PRINT MODE
Moves forward to the HEX
PRINT MODE option.
6. HEX PRINT MODE
DISABLE*
Moves forward to
DISABLE, the active
option.
7. HEX PRINT MODE
ENABLE
Moves forward to
ENABLE, the alternate
option.
8. HEX PRINT MODE
ENABLE*
Asterisk (*) indicates this
choice is now active.
9. NOT READY Returns the printer to the
NOT READY mode.
10. OPERATOR MENU
LOCKED
Press both keys at the
same time to relock the
Operator Menu.
11. READY
HEX DUMP ACTIVE
Returns the printer to the
READY mode.
The message HEX DUMP
ACTIVE flashes briefly.
12. A hex code printout results when data is sent to the printer with HEX PRINT MODE enabled.
After obtaining the printout, return to normal print mode by disabling HEX PRINT MODE.
NOTE: Printing in Hex Mode may alter prior print attributes set by the host computer. A soft reset
or power-off may be required after disabling HEX PRINT MODE.
Step Key Result Notes
