Inovance SV660P Series - Servo Motor Components (Flange Sizes 100;130;180)

Product Information
‑25‑
Table 1–6 Components of terminal‑type motors
No. Name
1
Encoder socket
2
Power socket
3
Mounting flange face
4
Mounting screw through‑hole
5
Shaft extension (with key)
Figure 1‑13 Components of lead wire‑type motors
Table 1–7 Components of lead wire‑type motors
No. Name
1
Power cable connector
2
Power cable
3
Mounting flange face
4
Output shaft
5
Encoder connector
6
Encoder cable
7
Encoder (detection part)
