Inovance SV660P Series - Page 29

Installation
‑28‑
Table 2–1 Dimensions of the outer packing box
Specifications
Outer Width
(mm)
Outer Height
(mm)
Outer Depth
(mm)
Size A
(SV660PS1R6I, SV660PS2R8I)
250.0 90.0 195
Size B
(SV660PS5R5I)
225.0 90 205.0
Size C
(SV660PS7R6I, SV660PT3R5I,
T5R4I)
235.0 105.0 215.0
Size D
(SV660PS012I, SV660PT8R4I, T012I)
235.0 130.0 225.0
Size E
(SV660PT017I, SV660PT021I, T026I)
320.0 150.0 280.0
1
2
3
4
Figure 2‑1 Contents inside the packing box
No. Name
1
Product
2
Terminal accessories (varying with product models)
