Inovance SV660P Series User Manual

Wiring
‑85‑
Servo Drive
Series
Servo Drive
Model
Rated
Input
Current
(A)
Recommended PVC Cable Model (at 40℃)
L1, L2/L1,
L2, L3
(mm
2
)
R, S, T
(mm
2
)
Cable Lug
(mm
2
)
Tightening
Torque
(N·m)
Size C
SV660PS7
R6I
9.6 1 ‑ ‑ ‑
Size D
SV660P
S012I
12.8 1.5 ‑ ‑ ‑
Three‑phase 220 V
Size C
SV660PS7
R6I
5.1 0.75
‑ ‑ ‑
Size D
SV660P
S012I
8 0.75 ‑ ‑ ‑
Three‑phase 380 V
Size C
SV660PT3
R5I
2.4
‑
0.75
‑ ‑
SV660PT5
R4I
3.6
‑ 0.75 ‑ ‑
Size D
SV660PT8
R4I
5.6 ‑ 0.75 ‑ ‑
SV660P
T012I
8 ‑ 0.75 ‑ ‑
Size E
SV660P
T017I
12
‑ 1.5 1.5 1.36
SV660P
T021I
16 ‑ 2.5 2.5 1.36
SV660P
T026I
21
‑
4 4 1.36
Table 3–13 Specifications of motor output cables
MS1H1/H4 05B–10C (Applicable to Motors with Rated Output of 50 W to 1 kW)
Cable type Regular cable
Flexible cable
Oil‑resistant shielded
flexible cable
Cable model
S6‑L‑M/B***‑X.X S6‑L‑M/B***‑X.X‑T S6‑L‑M/B***‑X.X‑TS
Cable
specifications
UL2517 (rated
temperature: 105℃)
4Ex20AWG+2Cx24AWG
UL2517 (rated
temperature: 105℃)
4Ex20AWG+2Cx24AWG
UL2517 (rated
temperature: 105℃)
4Ex20AWG+2Cx24AWG
Power cable: 20AWG
(0.52 mm
2
) Insulation
diameter: 1.7 mm
Power cable: 20AWG
(0.52 mm
2
) Insulation
diameter: 1.7 mm
Power cable: 20AWG
(0.52 mm
2
) Insulation
diameter: 1.7 mm
Brake cable: 24AWG
(0.205 mm
2
) Insulation
diameter: 1.1 mm
Brake cable: 24AWG
(0.205 mm
2
) Insulation
diameter: 1.1 mm
Brake cable: 24AWG
(0.205 mm
2
) Insulation
diameter: 1.1 mm
Sheath diameter 6.5±0.2 mm
