CUSA® Clarity System Service and Maintenance Manual Page 47 of 117 0645403-2-EN
EUT Sterilization Tray Configuration
1. Place the handpiece in the appropriate slot ➀ and align it with the outline on the boom of the tray.
2. Wrap the handpiece cable around the posts ➁.
3. Place the handpiece connector in the appropriate slot ➂ and align it with the outline on the boom of the tray.
4. Optional. Place the nosecone in the appropriate slot ➃ and align it with the outline on the boom of the tray.
5. Optional. Place the flue ➄ anywhere on the boom of the tray.
6. Place the torque base in the appropriate slot ➅ and align it with the outline on the boom of the tray.
7. Optional. Place the Extended Use Tips (up to 3) in the appropriate slots➆ and align them with the outline on the boom of the tray.
8. Put on the lid ➇ on the sterilizer tray.
9. Close and latch the lid.
Sterilization Parameters
Sterilize the CUSA Clarity handpiece and components with steam.
Sterilization Tray Packaging
Packaged in a sterilized tray, the handpiece and components are:
• Wrapped—Sterilization tray double wrapped in hospital CSR material
• Flash (Unwrapped)—Sterilization tray unwrapped
The cycles below are acceptable for sterilizing the CUSA Clarity handpiece and components
Packaging Temp Type Time Dry Cycle
Wrapped
132°C/269.6°F
134°C/273.2°F
134°C/273.2°F
Prevac 4 min 30 min
Prevac 3 min 30 min
Prevac 18 min 30 min
Flash 132°C/269.6°F Prevac 4 min None
Table 6-3 Sterilization Cycles
