Integra DRX-8.4 User Manual

160
SetupSetup
6. Hardware
 7. 12V Trigger C
Set when outputting the control signal (maximum 12 V/25 mA) through the 12V
TRIGGER OUT C jack. You can enable power link operation when you connect
the unit and the external devices equipped with 12V trigger input jack.
 Delay (Default Value: 2 sec)
Set after how many seconds the 12V trigger output will occur in response to
the unit's operation. As some devices cause a large current when they turn on,
delay the output if such devices are connected. Select a value between "0 sec"
to "3 sec".
 BD/DVD (Default Value: Main/Zone 2/Zone 3)
GAME (Default Value: Main/Zone 2/Zone 3)
CBL/SAT (Default Value: Main/Zone 2/Zone 3)
STRM BOX (Default Value: Main/Zone 2/Zone 3)
PC (Default Value: Main/Zone 2/Zone 3)
AUX (Default Value: Main)
CD (Default Value: Main/Zone 2/Zone 3)
TV (Default Value: Main/Zone 2/Zone 3)
PHONO (Default Value: Main/Zone 2/Zone 3)
TUNER (Default Value: Main/Zone 2/Zone 3)
NET (Default Value: Main/Zone 2/Zone 3)
BLUETOOTH (Default Value: Main/Zone 2/Zone 3)
Set the 12V trigger output setting to each input.
O󰀨 When the control signal is not output
Main When controlling the power of external devices linked to the
input selection in the main room
Zone 2 When controlling the power of external devices linked to the
input selection in ZONE 2
Main/Zone 2 When controlling the power of external devices linked to the
input selection in the main room or in ZONE 2
Zone 3 When controlling the power of external devices linked to the
input selection in ZONE 3
Main/Zone 3 When controlling the power of external devices linked to the
input selection in the main room or in ZONE 3
Zone 2/Zone 3 When controlling the power of external devices linked to the
input selection in ZONE 2 or in ZONE 3
Main/Zone 2/
Zone 3
When controlling the power of external devices linked to the
input selection in the main room, in ZONE 2 or in ZONE 3
• Only "O󰀨" and "Main" are available for selection with AUX input.

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
