5.1.4ch
7.1.2ch
7.1ch
5.1.2ch
7.1.4ch
5.1ch
60
Speaker Connections
7.1.4 Channel System + ZONE SPEAKER (ZONE 2/ZONE 3)
FL
FR
SL
SR
SBL SBR
SW
RHR
TMR
RHL
TML
C
MAIN ROOM
Playing Back (ZONE 2) ( p108)
Playing Back (ZONE 3) ( p110)
FL(Z3)FR(Z3)
ZONE 2
FL(Z2)FR(Z2)
ZONE 3
While ZONE 2 playback is being performed, surround back speakers installed in the main room cannot play audio.
While ZONE 2/ZONE 3 playback is being performed, surround back speakers and height 2 speakers installed in the main room cannot play audio.
*1 Connect the Height Speakers you have actually installed (HL1/HR1: Front Height Speakers, Top (front side) Speakers, Dolby Enabled Speakers (Front)).
*2 Connect the Height Speakers you have actually installed (HL2/HR2: Rear Height Speakers, Top (rear side) Speakers, Dolby Enabled Speakers (Surround,
Surround Back)).
*1 *2
*1*2
