Connector/Header Locations and Pin-outsIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
92 Revision 1.1
Intel order number G34153-003
29
LED_NIC_LINK2_LNKUP_FP_N
30
LED_NIC_LINK3_LNKUP_FP_N
6.2.2 Front Panel USB Connector
The server board includes a 10-pin connector, that when cabled, can provide up to two USB
ports to a front panel. The following table provides the connector pin-out.
Table 34. Front Panel USB Connector Pin-out
Pin
Signal Name
Pin
Signal Name
1
P5V_USB_FP
2
P5V_USB_FP
3
USB2_P13_F_DN
4
USB2_P11_F_DN
5
USB2_P13_F_DP
6
USB2_P11_F_DP
7
GND
8
GND
9
KEY
10
NA
6.2.3 Local Control Panel Connector
The server board includes a 7-pin connector that is used when the system is configured with the
Intel Local Control Panel with LCD support. The following table provides the pin-out for this
connector.
Table 35. Local Front Panel Connector Pin-out
Pin
Signal Name
Pin
Signal Name
1
SMB_SENSOR_3V3STBY_DATA
2
GND
3
SMB_SENSOR_3V3STBY_CLK
4
P3V3_AUX
5
FM_LCP_ENTER_N
6
FM_LCP_LEFT_N
7
FM_LCP_RIGHT_N
6.3 On Board Storage Connectors
The server board provides connectors for support of several storage device options. This
section provides a functional overview and pin-out of each connector.
6.3.1 SATA Connectors: 6Gbps
The board includes two white single port SATA only connectors capable of transfer rates of up
to 6Gb/s. The following table provides the pin-out for both connectors.
Table 36. SATA 6Gbps Connector Pin-out
Pin
Signal Name
1
GND
2
SATA_TX_P
3
SATA_TX_N
4
GND
5
SATA_RX_N
6
SATA_RX_P
7
GND
