Intel S2600IP User Manual

Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Appendix C: Platform
Specific BMC Appendix
Revision 1.1
Intel order number G34153-003
149
 Intel
®
Server Chassis P4224 (UPL with redundant fan 4U)
 Intel
®
Server Chassis P4308 (UPL with redundant fan 4U)
 Intel
®
Server Chassis P4XXX (UPL with redundant fan 4U)
 Intel
®
Server Chassis R2208 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2216 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2224 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2308 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2312 (BHP with redundant fan 2U)
Fan domain definition
Table 74. Intel
®
Server Board S2600IP - Fan Domain Definition
Chassis
Fan Domain
Major Components Cooled
(Temperature sensor number)
Fans
(Sensor number)
P4208/P4216/P4224/P4
308/P4XXX (UPL with
redundant fan 4U)
0
 SSB Temp(22h)
 BB BMC Temp(23h)
 BB MEM VR Temp(25h)
 I/O Mod Temp(26h)
 HSBP 1 Temp(29h)
 HSBP 2 Temp(2Ah)
 SAS Mod Temp(2Dh)
 Exit Air Temp(2Eh)
 LAN NIC Temp(2Fh)
System Fan 1(30h)
1
 SSB Temp(22h)
 BB BMC Temp(23h)
 BB MEM VR Temp(25h)
 I/O Mod Temp(26h)
 HSBP 1 Temp(29h)
 HSBP 2 Temp(2Ah)
 SAS Mod Temp(2Dh)
 Exit Air Temp(2Eh)
 LAN NIC Temp(2Fh)
System Fan 2(31h)
2
 BB P2 VR Temp(24h)
 BB MEM VR Temp(25h)
 HSBP 1 Temp(29h)
 HSBP 2 Temp(2Ah)
 HSBP 3 Temp(2Bh)
 SAS Mod Temp(2Dh)
 Exit Air Temp(2Eh)
 HDD 20 Status(64h)
 HDD 21 Status(65h)
 DIMM Thrm Mrgn 2(B1h)
 DIMM Thrm Mrgn 3(B2h)
System Fan 3(32h)
3
 BB P2 VR Temp(24h)
 HSBP 3 Temp(2Bh)
 Exit Air Temp(2Eh)
System Fan 4(33h)
