Intel S2600IP User Manual

Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSPlatform Management Overview
Revision 1.1 49
Intel order number G34153-003
Table 11. Basic and Advanced Features
Feature
Basic
Advanced
IPMI 2.0 Feature Support
X
X
In-circuit BMC Firmware Update
X
X
FRB 2
X
X
Chassis Intrusion Detection
X
X
Fan Redundancy Monitoring
X
X
Hot-Swap Fan Support
X
X
Acoustic Management
X
X
Diagnostic Beep Code Support
X
X
Power State Retention
X
X
ARP/DHCP Support
X
X
PECI Thermal Management Support
X
X
E-mail Alerting
X
X
Embedded Web Server
X
X
SSH Support
X
X
Integrated KVM
X
Integrated Remote Media Redirection
X
Lightweight Directory Access Protocol (LDAP)
X
X
Intel
®
Intelligent Power Node Manager Support
X
X
SMASH CLP
X
X
4.1.3 Integrated BMC Hardware: Emulex* Pilot III
4.1.3.1 Emulex* Pilot III Baseboard Management Controller Functionality
The Integrated BMC is provided by an embedded ARM9 controller and associated peripheral
functionality that is required for IPMI-based server management. Firmware usage of these
hardware features is platform dependent.
The following is a summary of the Integrated BMC management hardware features that
comprise the BMC:
 400MHz 32-bit ARM9 processor with memory management unit (MMU)
 Two independent10/100/1000 Ethernet Controllers with Reduced Media Independent
Interface (RMII)/ Reduced Gigabit Media Independent Interface (RGMII) support
 DDR2/3 16-bit interface with up to 800 MHz operation
 16 10-bit ADCs
 Sixteen fan tachometers
 Eight Pulse Width Modulators (PWM)
 Chassis intrusion logic
 JTAG Master
 Eight I
2
C interfaces with master-slave and SMBus* timeout support. All interfaces are
SMBus* 2.0 compliant.
 Parallel general-purpose I/O Ports (16 direct, 32 shared)
 Serial general-purpose I/O Ports (80 in and 80 out)
 Three UARTs
 Platform Environmental Control Interface (PECI)

Intel S2600IP Specifications

General

Brand	Intel
Model	S2600IP
Category	Motherboard
Language	English
