Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSConnector/Header Locations and Pin-outs
Revision 1.1 95
Intel order number G34153-003
6.3.7 Internal eUSB SSD Header
The server board includes one 10-pin internal eUSB header with an intended usage of
supporting USB SSD devices. The following table provides the pin-out for this connector.
Table 43. eUSB SSD Header Pin-out
Pin
Signal Name
Pin
Signal Name
1
5V
2
NC
3
USB2_P0_DN
4
NC
5
USB2_P0_DP
6
NC
7
GND
8
NC
9
Key
10
LED_HDD_ACT_ZEPHER_N
6.4 Management and Security Connectors
6.4.1 RMM4_Lite Connector
A 7-pin Intel
®
RMM4 Lite connector is included on the server board to support the optional Intel
®
Remote Management Module 4. There is no support for third-party management cards on this
server board.
Table 44. RMM4_Lite Connector Pin-out
Pin
Signal Name
Pin
Signal Name
1
P3V3_AUX
2
DI
3
KEY
4
CLK
5
DO
6
GND
7
CS_N
8
GND
6.4.2 RMM4_NIC Connector
Table 45. RMM4_NIC Connector Pin-out
Pin
Signal Name
Pin
Signal Name
1
3V3_AUX
2
MDIO
3
3V3_AUX
4
MDC
5
GND
6
TXD_0
7
GND
8
TXD_1
9
GND
10
TXD_2
11
GND
12
TXD_3
13
GND
14
TX_CTL
15
GND
16
RX_CTL
17
GND
18
RXD_0
19
GND
20
RXD_1
21
GND
22
RXD_2
23
GND
24
RXD_3
25
GND
26
TX_CLK
27
GND
28
RX_CLK
