Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Appendix C: Platform
Specific BMC Appendix
Revision 1.1
Intel order number G34153-003
153
 Intel
®
Server Chassis P4308 (UPL with redundant fan 4U)
 Intel
®
Server Chassis P4XXX (UPL with redundant fan 4U)
 Intel
®
Server Chassis R2208 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2216 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2224 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2308 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2312 (BHP with redundant fan 2U)
Memory Throttling support
 Baseboard supports this feature.
Intel
®
Workstation Board W2600CR
Introduction
This is an addendum document to BMC core EPS. This document describes platform and
chassis specific information.
Product ID
Bytes 11:12 (product ID) of Get Device ID command response: 56h 00h
IPMI Channel ID Assignments
The following table provides information on the BMC channel assignments:
Table 77. Intel
®
Workstation Board W2600CR - BMC Channel Assignments
Channel ID
Interface
Supports
Sessions
0
Primary IPMB
Yes
1
LAN 1
Yes
2
LAN 2 (platform specific)
Yes
3
LAN3
1
(Provided by the Intel
®
Dedicated Server Management NIC)
Yes
4
Reserved
Yes
5
USB
No
6
Secondary IPMB
No
7
SMM
No
8– 0Dh
Reserved
–
0Eh
Self
2
–
0Fh
SMS/Receive Message Queue
No
Notes:
1. Optional HW supported by the server system.
2. Refers to the actual channel used to send the request.
ACPI S3 Sleep State Support
Supported
