Connector/Header Locations and Pin-outsIntel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
94 Revision 1.1
Intel order number G34153-003
Pin
Signal name
Pin
Signal name
A14
SAS6_RX_C_DN
B14
SAS6_TX_C_DN
A15
GROUND
B15
GROUND
A16
SAS7_RX_C_DP
B16
SAS7_TX_C_DP
A17
SAS7_RX_C_DN
B17
SAS7_TX_C_DN
A18
GROUND
B18
GROUND
MTH1
GROUND
MTH5
GROUND
MTH2
GROUND
MTH6
GROUND
MTH3
GROUND
MTH7
GROUND
MTH4
GROUND
MTH8
GROUND
6.3.3 Intel
®
RAID C600 Upgrade Key Connector
The server board provides one connector to support Intel
®
RAID C600 Upgrade Key. The Intel
®
RAID C600 Upgrade Key is a small PCB board that enables different versions of RAID 5
software stack and/or upgrade from SATA to SAS storage functionality. The pin configuration of
connector is identical and defined in the following table.
Table 39. Intel
®
RAID C600 Upgrade Key Connector Pin-out
Pin
Signal Name
1
GND
2
FM_PBG_DYN_SKU_KEY
3
GND
4
FM_SSB_SAS_SATA_RAID_KEY
6.3.4 HSBP_I2C Header
Table 40. HSBP_I2C Header Pin-out
Pin
Signal Name
1
SMB_HSBP_3V3STBY_DATA
2
GND
3
SMB_HSBP_3V3STBY_CLK
6.3.5 HDD LED Header
The server board includes a 2-pin hard drive activity LED header used with some SAS/SATA
controller add-in cards. The header has the following pin-out.
Table 41. HDD LED Header Pin-out
Pin
Signal Name
Pin
Signal Name
1
LED_HDD_ACT_N
2
NA
6.3.6 Internal Type- A USB Connector
The server board includes two internal Type-A USB connector. The following table provides the
pin-out for this connector.
Table 42. Type-A USB Connector Pin-out
Pin
Signal Name
Pin
Signal Name
1
P5V
2
USB2_P2_F_DN
3
USB2_P2_F_DP
4
GND
