Functional Architecture Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
40 Revision 1.1
Intel order number G34153-003
Table 8. Intel
®
Server Board S2600IP/Workstation Board W2600CR PCI Bus Segment
Characteristics
Voltage
Width
Speed
Type
PCI I/O Card Slots
3.3 V
x16
32 GB/S
PCI
Express*
Gen3
X16 PCI Express* Gen3 throughput
to Slot1 (x16 mechanically)
3.3 V
X8 or none
(with mux)
16 GB/S or
none
PCI
Express*
Gen3
x8 PCI Express* Gen3 throughput
to Slot 2 (x8 mechanically)
3.3 V
x16 or x8(with
mux)
32 GB/S or
16 GB/S
PCI
Express*
Gen3
x16 PCI Express* Gen3 throughput
to Slot 3 (x16 mechanically)
3.3 V
X8 or none
(with mux)
16 GB/S or
none
PCI
Express*
Gen3
x8 PCI Express* Gen3 throughput
to Slot 4 (x8 mechanically, Non-
Persistent)
3.3 V
x16 or x8(with
mux)
32 GB/S or
16 GB/S
PCI
Express*
Gen3
X16 PCI Express* Gen3 throughput
to Slot 5 (x16 mechanically, Non-
Persistent)
3.3 V
X8 or none
(with mux)
16 GB/S or
none
PCI
Express*
Gen3
x8 PCI Express* Gen3 throughput
to Slot 6 (x8 mechanically, Non-
Persistent)
3.3 V
x16 or x8(with
mux)
32 GB/S or
16 GB/S
PCI
Express*
Gen3
X16 PCI Express* Gen3 throughput
to Slot 7 (x16 mechanically, Non-
Persistent)
3.3 V
X4
4 GB/S
PCI
Express*
Gen2
X4 PCI Express* Gen2 throughput
to Slot 8 (x8 mechanically, Non-
Persistent)
3.5 Network Interface Controller
The Intel
®
Server Board S2600IP and Workstation Board S2600CR has a Intel
®
Ethernet
Controller I350 GbE Controller. The controller supports PCI Express* PCIe v2.0 (5GT/s and
2.5GT/s). The controller enables four-port or two-port 1000BASE-T implementations using
integrated PHY’s. The controller supports VMDq, SR-IOV, EEE, and DMA Coalescing.
3.5.1 Network Interface
Network connectivity is provided by means of an onboard Intel
®
Ethernet Controller 1350-AM4
providing up to four 10/100/1000 Mb Ethernet ports.
On the Intel
®
Server Board S2600IP, four external 10/100/1000 Mb RJ45 Ethernet ports are
provided. On the Intel
®
Workstation Board W2600CR, two external 10/100/1000 Mb RJ45
Ethernet ports are provided. Each Ethernet port drives two LEDs located on each network
interface connector. The LED at the right of the connector is the link/activity LED and indicates
network connection when on, and transmit/receive activity when blinking. The LED at the left of
the connector indicates link speed as defined in the following table.
