Appendix C: Platform Specific BMC Appendix Intel® Server Board S2600IP and Intel® Workstation
Board W2600CR TPS
Revision 1.1
Intel order number G34153-003
152
 Intel
®
Server Chassis R2312 (BHP)
o 12-bay 3.5” HDD – F2U12X35HSBP
Power unit support
 Intel
®
Server Chassis P4208/P4216/P4224/P4308 (UPL)
Table 75. Intel
®
Server Chassis P4208/P4216/P4224/P4308 (UPL) Power support
PS Module
Number
PMBus*
Product Name
(in product
area of the
FRU)
PSU
Redundant
Cold
Redundant
Fans in
each PS
750W HS
Power Supply
Supported
DPS-750XB A
Supported
Supported
1 PS fan
1200W HS
Power Supply
Supported
DPS-1200TB A
Supported
Supported
2 PS fan
 Intel
®
Server Chassis R2208/R2216/R2224/R2308/R2312 (BHP)
Table 76. Intel
®
Server Chassis R2208/R2216/R2224/R2308/R2312 (BHP) Power support
PS Module
Number
PMBus*
Product
Name(in
product area of
the FRU)
PSU
Redundant
Cold
Redundant
Fans in
each PS
750W HS
Power Supply
Supported
FS750HS1-00
Supported
Supported
1 PS fan
Redundant Fans only for Intel
®
Server Chassis
 Intel
®
Server Chassis P4208 (UPL with redundant fan 4U)
 Intel
®
Server Chassis P4216 (UPL with redundant fan 4U)
 Intel
®
Server Chassis P4224 (UPL with redundant fan 4U)
 Intel
®
Server Chassis P4308 (UPL with redundant fan 4U)
 Intel
®
Server Chassis P4XXX (UPL with redundant fan 4U)
 Intel
®
Server Chassis R2208 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2216 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2224 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2308 (BHP with redundant fan 2U)
 Intel
®
Server Chassis R2312 (BHP with redundant fan 2U)
Fan Fault LED support
Fan fault LEDs are available on the baseboard and on the hot-swap redundant fans
available on the following chassis:
 Intel
®
Server Chassis P4208 (UPL with redundant fan 4U)
 Intel
®
Server Chassis P4216 (UPL with redundant fan 4U)
 Intel
®
Server Chassis P4224 (UPL with redundant fan 4U)
