Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Appendix C: Platform
Specific BMC Appendix
Revision 1.1
Intel order number G34153-003
151
Chassis
Fan Domain
Major Components Cooled
(Temperature sensor number)
Fans
(Sensor number)
 P2 Therm Margin(75h)
 DIMM Thrm Mrgn 1(B0h)
 DIMM Thrm Mrgn 2(B1h)
 DIMM Thrm Mrgn 3(B2h)
 DIMM Thrm Mrgn 4(B3h)
4
 SSB Temp(22h)
 BB P2 VR Temp(24h)
 HSBP 1 Temp(29h)
 HSBP 2 Temp(2Ah)
 P1 Therm Margin(74h)
 P2 Therm Margin(75h)
 P2 DTS Therm Mgn(84h)
 DIMM Thrm Mrgn 2(B1h)
 DIMM Thrm Mrgn 3(B2h)
System Fan 5(34h)
5
 BB P2 VR Temp(24h)
 HSBP 1 Temp(29h)
 HSBP 2 Temp(2Ah)
 HSBP 3 Temp(2Bh)
 Exit Air Temp(2Eh)
 P1 Therm Margin(74h)
 P2 Therm Margin(75h)
 DIMM Thrm Mrgn 1(B0h)
 DIMM Thrm Mrgn 2(B1h)
 DIMM Thrm Mrgn 3(B2h)
 DIMM Thrm Mrgn 4(B3h)
System Fan 6(35h)
HSC Availability
 Intel
®
Server Chassis P4208 (UPL)
o 8-bay 2.5” HDD – FXX8X25HSBP
 Intel
®
Server Chassis P4216 (UPL)
o 8-bay 2.5” HDD – FXX8X25HSBP
 Intel
®
Server Chassis P4224 (UPL)
o 8-bay 2.5” HDD – FXX8X25HSBP
 Intel
®
Server Chassis P4308 (UPL)
o 8-bay 3.5” HDD – FUP8X35HSBP
 Intel
®
Server Chassis R2208 (BHP)
o 8-bay 2.5” HDD – FXX8X25HSBP
 Intel
®
Server Chassis R2216 (BHP)
o 8-bay 2.5” HDD – FXX8X25HSBP
 Intel
®
Server Chassis R2224 (BHP)
o 8-bay 2.5” HDD – FXX8X25HSBP
 Intel
®
Server Chassis R2308 (BHP)
o 8-bay 3.5” HDD – F2U8X35HSBP
