Appendix C: Platform Specific BMC Appendix Intel® Server Board S2600IP and Intel® Workstation
Board W2600CR TPS
Revision 1.1
Intel order number G34153-003
150
Chassis
Fan Domain
Major Components Cooled
(Temperature sensor number)
Fans
(Sensor number)
 P1 Therm Margin(74h)
 P2 Therm Margin(75h)
 DIMM Thrm Mrgn 1(B0h)
 DIMM Thrm Mrgn 4(B3h)
4
 BB P2 VR Temp(24h)
 HSBP 3 Temp(2Bh)
 Exit Air Temp(2Eh)
 PS1 Temperature(5Ch)
 PS2 Temperature(5Dh)
 HDD 20 Status(64h)
 HDD 21 Status(65h)
 DIMM Thrm Mrgn 1(B0h)
 DIMM Thrm Mrgn 4(B3h)
System Fan 5(34h)
R2208/R2216/R2224/P2
308/P2312 (BHP with
redundant fan 2U)
0
 SSB Temp(22h)
 BB BMC Temp(23h)
 BB MEM VR Temp(25h)
 I/O Mod Temp(26h)
 HSBP 1 Temp(29h)
 HSBP 2 Temp(2Ah)
 SAS Mod Temp(2Dh)
 Exit Air Temp(2Eh)
 LAN NIC Temp(2Fh)
System Fan 1(30h)
1
 SSB Temp(22h)
 BB BMC Temp(23h)
 BB MEM VR Temp(25h)
 I/O Mod Temp(26h)
 HSBP 1 Temp(29h)
 HSBP 2 Temp(2Ah)
 SAS Mod Temp(2Dh)
 Exit Air Temp(2Eh)
 LAN NIC Temp(2Fh)
System Fan 2(31h)
2
 SSB Temp(22h)
 BB P2 VR Temp(24h)
 HSBP 1 Temp(29h)
 HSBP 2 Temp(2Ah)
 P1 Therm Margin(74h)
 P2 Therm Margin(75h)
 P2 DTS Therm Mgn(84h)
 DIMM Thrm Mrgn 2(B1h)
 DIMM Thrm Mrgn 3(B2h)
System Fan 3(32h)
3
 BB P2 VR Temp(24h)
 HSBP 1 Temp(29h)
 HSBP 2 Temp(2Ah)
 HSBP 3 Temp(2Bh)
 Exit Air Temp(2Eh)
 P1 Therm Margin(74h)
System Fan 4(33h)
