Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Product Overview
Revision 1.1 3
Intel order number G34153-003
2.1 Product Feature Set
Table 1. Product Feature Set
Board Name
Intel
®
Server Board S2600IP
Intel
®
Workstation Board W2600CR
Processors
 Support for one or two Intel
®
Xeon
®
E5-
2600 Processor(s)
 8 GT/s Intel
®
Quick Path Interconnect
(Intel
®
QPI)
 LGA 2011 Socket
 Thermal Design Power up to 135 W
 Support for one or two Intel
®
Xeon
®
E5-
2600 Processor(s)
 8 GT/s Intel
®
Quick Path Interconnect (Intel
®
QPI)
 LGA 2011 Socket
 Thermal Design Power up to 150 W
Chipset
Intel
®
C600-A chipset with support for optional Intel
®
C600 RAID Upgrade Keys
Memory
 16 DDR3 DIMMs with 800MT/s, 1067MT/s, 1333MT/s,1600MT/s
 Eight memory channels (four channels for each processor socket)
 Channels A, B, C, D, E, F, G and H
 Support for 800/1066/1333/1600 MHz/s Registered DDR3 Memory (RDIMM),
 Unbuffered DDR3 memory ((UDIMM) and Load Reduced DDR3 memory (LRDIMM)
 DDR3 standard I/O voltage of 1.5V and DDR3 Low Voltage of 1.35V
Slots
 Slot 1: PCIe Gen3 x16, connector from first processor.
 Slot 2: PCIe Gen3 x8, connector from first processor.
 Slot 3: PCIe Gen3 x16, connector from first processor.
 Slot 4: PCIe Gen3 x8, connector from second processor.
 Slot 5: PCIe Gen3 x16, connector from second processor.
 Slot 6: PCIe Gen3 x8, connector, from second processor
 Slot 7: PCIe Gen3 x16,connector, from second processor
 Slot 8: PCIe Gen2 x4 electrical with x8 physical connector, from second processor
IOM Connector: I/O Module (optional with Flex Cable*)
Notes: The IOM connector is not available for all boards and only supports PCIe Gen1 Speed
SM Conn: SAS Module (optional)
 6Gbps or 12Gbps SAS ROC module Options
Ethernet
Intel
®
I350 Quad 1GbE fully integrated GbE
MAC and PHY Network Controller
Intel
®
I350 Dual 1GbE fully integrated GbE MAC
and PHY Controller
On-board storage
controllers and
options
 One eUSB 2x5 pin connector to support 2mm low-profile eUSB solid state devices
 Two 7-pin single port AHCI SATA connectors capable of supporting up to 6 GB/sec
 Two SCU 4-port mini-SAS connectors capable of supporting up to 3 GB/sec SAS/SATA
 Intel
®
Integrated RAID module support (Optional)
 Intel
®
RAID C600 Upgrade Key support providing optional expanded SATA/SAS RAID
capabilities
Video
 Integrated Matrox* G200 2D Video
Graphics controller
 1 Rear VGA port
 Integrated Matrox* G200 2D Video
Graphics controller
 1 Internal VGA connector
