Appendix B: BMC Sensor Tables Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Revision 1.1
Intel order number G34153-003
124
Note: All sensors listed below may not be present on all platforms. Please check platform EPS section for platform applicability and
platform chassis section for chassis specific sensors. Redundancy sensors will be only present on systems with appropriate
hardware to support redundancy (for instance, fan or power supply).
Table 71. Integrated BMC Core Sensors
Full Sensor
Name
(Sensor name
in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Reading
Type
Event Offset
Triggers
Contrib.
To
System
Status
Assert/De-
assert
Readable
Value/
Offsets
Event
Data
Rearm
Stand-
by
Power Unit
Status
(Pwr Unit
Status)
01h
All
Power Unit
09h
Sensor
Specific
6Fh
00 - Power down
OK
As and De
–
Trig
Offset
A
X
02 - 240 VA
power down
Fatal
04 - A/C lost
OK
05 - Soft power
control failure
Fatal
06 - Power unit
failure
Power Unit
Redundancy
1
(Pwr Unit
Redund)
02h
Chassis-
specific
Power Unit
09h
Generic
0Bh
00 - Fully
Redundant
OK
As and De
–
Trig
Offset
M
X
01 - Redundancy
lost
Degraded
02 - Redundancy
degraded
Degraded
03 - Non-
redundant:
sufficient
resources.
Transition from full
redundant state.
Degraded
04 – Non-
redundant:
sufficient
resources.
Transition from
insufficient state.
Degraded
