Appendix C: Platform Specific BMC Appendix Intel® Server Board S2600IP and Intel® Workstation
Board W2600CR TPS
Revision 1.1
Intel order number G34153-003
154
Processor Support for Intel
®
Server Board W2600CR
 Intel
®
Xeon
®
processor E5-2600 product family up to 150 Watt
 Intel
®
Xeon
®
processor E5-2600 v2 product family up to 150 Watt
Supported Chassis
 Intel
®
Server Chassis P4304 (UPL with fixed fan 4U)
Chassis-specific sensors
Table 78. Intel
®
Workstation Board W2600CR - Chassis-specific sensors
Intel
®
Server Chassis
Fan Tachometer Sensors
Fan
Presen
e
Sensor
s
Physical Security
(Chassis intrusion)
sensor
FP Interrupt
(FP NMI Diag Int)
P4304 (UPL with
fixed fan 4U)
System Fan 1(30h)
NA
Physical Scrty(04h)
FP NMI Diag Int(05h)
System Fan 2(31h)
NA
NA
NA
Processor 1 Fan (36h)
NA
NA
NA
Processor 2 Fan (37h)
detected
NA
NA
NA
Hot-plug fan support
Not supported.
Fan redundancy support
Not supported.
Board specific feature
Board has not supported serial port A, and SOL will only use serial port B.
Fan domain definition
Table 79. Intel
®
Workstation Board W2600CR - Fan domain definition
Chassis
Fan Domain
Major Components Cooled
(Temperature sensor number)
Fans
(Sensor number)
P4304 (UPL
with fixed
fan 4U)
0
 SSB Temp(22h)
 BB BMC Temp(23h)
 BB MEM VR Temp(25h)
 I/O Mod Temp(26h)
 SAS Mod Temp(2Dh)
 Exit Air Temp(2Eh)
 LAN NIC Temp(2Fh)
 DIMM Thrm Mrgn 2(B1h)
 DIMM Thrm Mrgn 3(B2h)
System Fan 1(30h)
1
 BB P2 VR Temp(24h)
 BB MEM VR Temp(25h)
 Exit Air Temp(2Eh)
 HDD 20 Status(64h)
 HDD 21 Status(65h)
System Fan 2(31h)
