Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Appendix E: POST Error Messages and Handling
Revision 1.1
Intel order number G34153-003
167
Error Code
Error Message
Response
85ED
DIMM_P1 encountered a Serial Presence Detection (SPD) failure
Major
85EE
DIMM_P2 encountered a Serial Presence Detection (SPD) failure
Major
85EF
DIMM_P3 encountered a Serial Presence Detection (SPD) failure
Major
8604
POST Reclaim of non-critical NVRAM variables
Minor
8605
BIOS Settings are corrupted
Major
8606
NVRAM variable space was corrupted and has been reinitialized
Major
92A3
Serial port component was not detected
Major
92A9
Serial port component encountered a resource conflict error
Major
A000
TPM device not detected.
Minor
A001
TPM device missing or not responding.
Minor
A002
TPM device failure.
Minor
A003
TPM device failed self test.
Minor
A100
BIOS ACM Error
Major
A421
PCI component encountered a SERR error
Fatal
A5A0
PCI Express* component encountered a PERR error
Minor
A5A1
PCI Express* component encountered an SERR error
Fatal
A6A0
DXE Boot Services driver: Not enough memory available to shadow a
Legacy Option ROM.
Minor
POST Error Beep Codes
The following table lists the POST error beep codes. Prior to system video initialization, the
BIOS uses these beep codes to inform users on error conditions. The beep code is followed by
a user-visible code on the POST Progress LEDs
Table 86. POST Error Beep Codes
Beeps
Error Message
POST Progress Code
Description
1
USB device action
NA
Short beep sounded whenever a USB device is discovered
in POST, or inserted or removed during runtime
1 long
Intel
®
TXT security
violation
0xAE, 0xAF
System halted because Intel
®
Trusted Execution
Technology detected a potential violation of system
security.
3
Memory error
See Tables 28 and 29
System halted because a fatal error related to the memory
was detected.
2
BIOS Recovery
started
NA
Recovery boot has been initiated
4
BIOS Recovery
failure
NA
BIOS recovery has failed. This typically happens so quickly
after recovery us initiated that it sounds like a 2-4 beep
code.
The Integrated BMC may generate beep codes upon detection of failure conditions. Beep codes
are sounded each time the problem is discovered, such as on each power-up attempt, but are
not sounded continuously. Codes that are common across all Intel server boards and systems
that use same generation chipset are listed in the following table. Each digit in the code is
represented by a sequence of beeps whose count is equal to the digit.
