Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Appendix B: BMC Sensor
Tables
Revision 1.1
Intel order number G34153-003
135
Full Sensor
Name
(Sensor name
in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Reading
Type
Event Offset
Triggers
Contrib.
To
System
Status
Assert/De-
assert
Readable
Value/
Offsets
Event
Data
Rearm
Stand-
by
Processor 4
Thermal
Control %
(P4 Therm Ctrl
%)
7Bh
Platform-
specific
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-
fatal
As and De
Analog
Trig
Offset
A
–
Processor 1
ERR2 Timeout
(P1 ERR2)
7Ch
All
Processor
07h
Digital Discrete
03h
01 – State
Asserted
fatal
As and De
–
Trig
Offset
A
–
Processor 2
ERR2 Timeout
(P2 ERR2)
7Dh
All
Processor
07h
Digital Discrete
03h
01 – State
Asserted
fatal
As and De
–
Trig
Offset
A
–
Processor 3
ERR2 Timeout
(P3 ERR2)
7Eh
Platform-
specific
Processor
07h
Digital Discrete
03h
01 – State
Asserted
fatal
As and De
–
Trig
Offset
A
–
Processor 4
ERR2 Timeout
(P4 ERR2)
7Fh
Platform-
specific
Processor
07h
Digital Discrete
03h
01 – State
Asserted
fatal
As and De
–
Trig
Offset
A
–
Catastrophic
Error
(CATERR)
80h
All
Processor
07h
Digital Discrete
03h
01 – State
Asserted
fatal
As and De
–
Trig
Offset
M
–
Processor1
MSID Mismatch
(P1 MSID
Mismatch)
81h
All
Processor
07h
Digital Discrete
03h
01 – State
Asserted
fatal
As and De
–
Trig
Offset
M
–
Processor
Population
Fault
(CPU Missing)
82h
All
Processor
07h
Digital Discrete
03h
01 – State
Asserted
Fatal
As and De
–
Trig
Offset
M
–
Processor 1
DTS Thermal
Margin
(P1 DTS Therm
Mgn)
83h
All
Temperature
01h
Threshold
01h
-
-
-
Analog
R, T
A
–
