Intel® Server Board S5500WB TPS Introduction
Revision 1.3
Intel order number E53971-004
1
1. Introduction
The Intel
®
Server Board S5500WB is a dual socket server using the Intel
®
Xeon
®
Processor
5500 series processor, in combination with the IOH and ICH10R to provide a balanced feature
set between technology leadership and cost.
1.1 Section Outline
This document is divided into the following chapters:
• Section 1 – Introduction
• Section 2 – Server Board Overview
• Section 3 – Functional Architecture
• Section 4 – I/O Expansion Modules
• Section 5 – Platform Management Features
• Section 6 – Configuration Jumpers
• Section 7 – Connector and Header Location and Pin-out
• Section 8 – Intel
®
Light-Guided Diagnostics
• Section 9 – Design and Environmental Specifications
• Section 10 – Power Subsystem
• Section 11 - Regulatory and Certification Information
• Appendix A – POST Code LED Decoder
• Appendix B – Video POST Code Errors
1.2 Server Board Use Disclaimer
Intel Corporation server boards contain a number of high-density VLSI and power delivery
components that need adequate airflow to cool. Intel ensures through its own chassis
development and testing that when Intel server building blocks are used together, the fully
integrated system will meet the intended thermal requirements of these components. It is the
responsibility of the system integrator who chooses not to use Intel developed server building
blocks to consult vendor datasheets and operating parameters to determine the amount of air
flow required for their specific application and environmental conditions. Intel Corporation
cannot be held responsible if components fail or the server board does not operate correctly
when used outside any of their published operating or non-operating limits.
