Intel® Server Board S5500WB TPS Platform Management Features
Revision 1.3
Intel order number E53971-004
41
5.2.3 BMC Basic Features
Feature Description
IPMI 2.0 Compliance to IPMI 2.0 specification
Remote Management Out-of-band access via either LAN or serial port for numerous features
Hardware Monitor Monitor of fans, voltages, temperatures, chassis intrusions, memory errors,
power supplies, hard drives, and so forth
Event Management System event filtering
Event Alerting System events delivered via SNMP traps or email
System Event Log Dedicated persistent storage for system events
Asset Inventory Field replaceable unit (FRU) information
Console Redirection Text-based console redirection via serial-over-LAN
SMASH CLP (Basic) Command line SSH interface for basic server management operations
Node Manager Power management by using P-state\C-State cycling method Requires
PMBus* power supply.
5.2.4 BMC Advanced Features
The Intel
®
Server Board S5500WB product includes support for an upgrade module to support
the advanced server management functionality. The Remote Management Module 3 supports
an 8 MB SPI Flash, which connects to the integrated BMC SPI interface. This is in addition to
the local integrated BMC 8 MB SPI flash connected to the PILOT II IBMC down on the board.
The total 16 MB of Flash space is required to support advanced management features as
defined in the following table. The RMM3 advanced management board has a PHY device that
which interfaces with the secondary NC-SI port out of the Server Engines PILOT II integrated
BMC to offer a dedicated management Ethernet port.
Table 14. Advanced Features
Manageability features Description
Embedded Web UI
Remote Power on\off, sensor status, system info,
System Event log, OEM customization
KVM Redirection high performance, multiple concurrent sessions
USB 2.0 Media Redirection boot over remote media
Security SSL, SSH support
WS- MAN
Dedicated NIC
Shared NIC (Onboard NICs)
LDAP support
