Connector / Header Locations and Pin-out Intel® Server Board S5500WB TPS
Revision 1.3
Intel order number E53971-004
60
Pin
Side
B PCI Express* Signal PCI Express* Signal
Pin
Side
A
Pin
Side
B PCI Express* Signal PCI Express* Signal
Pin
Side
A
34 PETxN4 GND 34 76 GND PERxP14 76
35 GND PERxP4 35 77 GND PERxN14 77
36
GND PERxN4
36
78 PETxP15 GND 78
37
PETxP5 GND
37
79 PETxN15 GND 79
38
PETxN5 GND
38
80 GND PERxP15 80
39
GND PERxP5
39
81 PRSNT2# PERxN15 81
40
GND PERxN5
40
82 RSVD GND 82
Table 37. Slot 1 PCI Express* x8 Connector (J1B3)
Pin-Side B PCI Express* Spec Signal Description Pin-Side A PCI Express* Spec
Signal
Description
1 12V 1 Reserved
2 12V 2 12V
3 Reserved 3 12V
4 GND 4 GND
5 SMCLK 5 JTAG-TCK
6 SMDATA 6 JTAG-TDI
7 GND 7 JTAG-TDO
8 3.3V 8 JTAG-TMS
9 JTAG-TRST# 9 3.3V
10 3.3VAux 10 3.3V
11 Wake# 11 PERST#
KEY KEY KEY KEY
KEY KEY KEY KEY
12 Reserved 12 GND
13 GND 13 REFCLK1+
14 PETp(0) 14 REFCLK1+
15 PETn(0) 15 GND
16 GND 16 PERp(0)
17 Reserved 17 PERn(0)
18 GND 1X end 18 GND
19 PETp(1) 19 Reserved
20 PETn(1) 20 GND
21 GND 21 PERp(1)
22 GND 22 PERn(1)
23 PETp(2) 23 GND
24 PETn(2) 24 GND
25 GND 25 PERp(2)
26 GND 26 PERn(2)
27 PETp(3) 27 GND
28 PETn(3) 28 GND
29 GND 29 PERp(3)
30 Reserved 30 PERn(3)
31 PRSNT2# 31 GND
32 GND 4X end 32 Reserved
33 33 Reserved
34 34 GND
35 GND 35
36 GND 36
37 37 GND
38 38 GND
