Intel® Light-Guided Diagnostics Intel® Server Board S5500WB TPS
Revision 1.3
Intel order number E53971-004
74
8.6 Front Panel Support
The Intel
®
Server Board S5500WB supports SSI standard front panel boards. The front panel
support is provided by a SSI compatible 2x12-pin signal connector. The front panel connector
supports the following diagnostic LEDs.
Table 51. Standard Front Panel Functionality
LED Color Condition What It Means
Green On Power on or S0 sleep
Green Blink S1 sleep
Power/Sleep
Off Off (also sleep S5 modes)
Green On System ready/No alarm
Green Blink
System ready, but degraded: redundancy lost such as
power supply or fan failure; non-critical temp/voltage
threshold; battery failure; or predictive PS failure.
Amber On
Critical alarm: Voltage, thermal, or power fault; CPU1
missing; insufficient power unit redundancy resource
offset asserted
Amber Blink
Non-Critical failure: Critical temp/voltage threshold;
VDR hot asserted; min number fans not present or
failed
Status
Off
AC power off: System unplugged
AC power on: System powered off and in standby, no
prior degraded\non-critical\critical state
Green Blink HDD access
Amber
Not
Supported
HDD fault
Amber
Not
Supported
Predictive failure, rebuild, identify
HDD
Off No access
Green On LAN link/ no access
Green Blink LAN access
LAN #1 -
Activity
Off Idle
Green On LAN link/ no access
Green Blink LAN access
LAN #2 -
Activity
Off Idle
Blue On Front panel chassis ID button pressed
Blue Blink Unit selected for identification via software
Identification
Off No identification
