Connector / Header Locations and Pin-out Intel® Server Board S5500WB TPS
Revision 1.3
Intel order number E53971-004
52
Pin Signal Name
1
GND
2
GND
3
GND
4
GND
5
+12V
6
+12V
7
+12V
8
+12V
Table 26. 12-V Only Power Control (replaces the 1x5 power control) (J9D1)
(FOXCONN ELECTRONICS INC HF1107V-P1 or TYCO ELECTRONICS CORPORATION 5-104809-6)
Pin Signal Name
1
SMB_PWR_CLK
2
SMB_PWR_DAT
3
SMB_PWR_ALRT
4
Remote Sense Return
5
12V Remote Sense
6
PS_ON
7
5V S/B
Table 27. Peripheral Power (Only for 12-V only SKU) (J8K2)
(iPN: C22293-003
MOLEX CONNECTOR CORPORATION 43045-0627 )
Note: This connector is for output power only. The 5V is limited to 6.5A and the 3.3V is limited
to 2A. Pin 4 is a 3.3V output Power Good signal if needed for a backplane
Pin Signal Name
1
5V
2
5V
3
GND
4
Powergood
5
3.3V
6
GND
