Functional Architecture Intel® Server Board S5500WB TPS
Revision 1.3
Intel order number E53971-004
34
3.11 Wake-up Control
Wake from S1 is supported on LAN, USB, Serial port, and PCI Express* slots.
3.12 Integrated Video Support
The SVGA subsystem supports a variety of modes, up to 1600 x 1200 resolution in 8 / 16 /
32 bpp modes under 2D. It also supports both CRT and LCD monitors up to a 200 Hz vertical
refresh rate.
The video is accessed using a standard 15-pin VGA connector found in the I/O panel area of
the server board. You can disable the onboard video controller using the BIOS Setup utility or
when an add-in video card is detected. The system BIOS provides the option for dual-video
operation when an add-in video card is configured in the system.
3.12.1 Video Modes
The integrated video controller supports all standard VGA modes. The following table shows the
2D modes supported for both CRT and LCD.
Table 9. Supported Video Modes
2D Video Mode Support 2D Mode Refresh Rate (Hz)
8 bpp 16 bpp 32 bpp
640x480 60, 72, 75, 85, 90,
100, 120, 160, 200
Supported Supported Supported
800x600 60, 70, 72, 75, 85,
90, 100, 120,160
Supported Supported Supported
1024x768 60, 70, 72,
75,85,90,100
Supported Supported Supported
1152x864 43,47,60,70,75,80,85 Supported Supported Supported
1280x1024 60,70,74,75 Supported Supported Supported
1600x1200 52 Supported Supported Supported
3.12.2 Dual Video
The BIOS supports both single-video and dual-video modes. The dual-video mode is enabled
by default in the BIOS.
In the single mode (dual monitor video = disabled), the onboard video controller is disabled
when an add-in video card is detected.
In the dual mode (onboard video = enabled, dual monitor video = enabled), the onboard video
controller is enabled and is the primary video device. The external video card is allocated
resources and is considered the secondary video device. The BIOS Setup utility provides
options to configure the feature as follows.
