Intel® Server Board S5500WB TPS Intel® I/O Expansion Modules
Revision 1.3
Intel order number E53971-004
37
4. Intel
®
I/O Expansion Modules
The Intel
®
Server Board S5500WB supports a variety of I/O Module options using 2x4 PCI
Express* Gen2 Intel
®
I/O Expansion Module connectors on the rear of the server board. Each
Intel
®
I/O Expansion Module connector is a 50-pin, surface mount, 0.8mm pitch, header. The
Intel
®
Server Board S5500WB accommodates both the double-wide I/O expansion modules and
the PCI Express* Gen 1 I/O modules (used on the S5000PAL rack server).
The Legacy modules are:
• Dual Port GbE I/O Module
• External 4 Port SAS I/O Module
The new modules consist of:
• Internal 4-port Intel 82576EB GbE*
• Dual Port Intel 10GbE I/O Module
• Internal 4-port LSI* 1064e SAS I/O Module
• Internal 4-port LSI* 1078e SAS I/O Module
• Infiniband* I/O Expansion Module Single Port QDR
The second x4 Intel
®
I/O Expansion Module controller does not support a single-wide module; it
is only used to support a double-wide module. You must mount single-wide modules on
connector (J3B1) closest to Slot 6, marked Legacy Intel
®
I/O Expansion Module on the
silkscreen. When double-wide Intel
®
I/O Expansion Modules are installed, there might be
interference with some adapters installed in Slot 1.
The following table shows the product codes for each module.
Table 13. Intel
®
I/O Expansion Module Product Codes
Product Code Description
AXX4SASMOD
Intel
®
SAS Entry RAID I/O Expansion Module: Provides 4-
port pass through SAS, entry-level RAID 0/1/1E, and
optional host RAID (4 internal ports).
AXXGBIOMOD Dual Gigabit Ethernet I/O Expansion Module
AXXROMBSASMR
Intel
®
Integrated RAID I/O Expansion Module: Provides four
internal ports, full-featured SAS / SATA RAID 0,1,5,6 and
striping capability for spans 10, 50, 60. You must order the
optional backup battery AXXRSBBU3 separately.
AXXSASIOMOD External 4-port SAS I/O Expansion Module.
AXX10GBIOMOD
Dual-port 10 Gigabit Ethernet I/O Expansion Module with
CX4 connectors.
