Server Board Overview Intel® Server Board S5500WB TPS
Revision 1.3
Intel order number E53971-004
2
2. Server Board Overview
The Intel
®
Server Board S5500WB is a monolithic printed circuit board (PCB) with features
designed to support the Internet Portal Data Center markets. The following table provides a
high-level product feature list.
Table 1. Intel
®
Server Board S5500WB Feature Set
Feature Description
Processors Support for one or two Intel
®
Xeon
®
Processor 5500 series processors in FC-LGA
1366 Socket B package with up to 95 W Thermal Design Power (TDP)
Supports future processor compatibility guidelines
4.8 GT/s, 5.86 GT/s, and 6.4 GT/s Intel
®
QuickPath Interconnect (Intel
®
QPI)
Meets EVRD11.1
Memory Support for 800/1066/1333 MT/s ECC registered (RDIMM) or unbuffered (UDIMM)
DDR3 memory.
8 DIMMs total across six memory channels (three channels per processor in a
2:1:1 configuration)
VRD optimized to support QR x8 DIMMs
No support for QR x4 DIMMs
Chipset
Intel
®
5500 Chipset IOH
Intel
®
82801Jx I/O Controller Hub (ICH10R)
I/O Control External connections:
DB-15 Video connectors
RJ-45 serial Port A connector
RJ-45 connector for 10/100/1000 LAN
One 2x USB 2.0 connectors
One RJ-45 over USB for 10/100/1000 LAN
Internal connections:
Two USB 2x5 pin header, supporting four USB 2.0 ports
One low-profile USB 2x5 pin
One DH-10 Serial Port B header
One 2x8 pin VGA header with presence detection to switch from rear I/O video
connector
Six SATA II connectors
Intel
®
I/O Expansion Module Dual Connectors
One RMM3 connector to support optional Intel
®
Remote Management Module 3
SATA SW RAID 5 Activation Key Connector
One SSI-EEB compliant front panel header
