Intel® Server Board S5500WB TPS Server Board Overview
Revision 1.3
Intel order number E53971-004
3
Feature Description
Power Connections
SSI SKU
One SSI-EEB compliant 24-pin main power connector (SSI only SKU)
One SSI compliant 8-pin CPU power connector
One SSI compliant 5-pin power control Connector (SSI only SKU)
12-V Only SKU
One 8-pin power connector
One 6-pin Aux power connector for 3.3 V and 5 V
One 7-pin power control connector
System Fan Support Two 8-pin fan headers for double rotor memory fans and six 4-pin fan headers
supporting two processor zones and two memory zones in a redundant fashion
Add-in Adapter Support One riser slot supporting both full-height and low-profile 1U and 2U MD2 PCI
Express* x16 riser cards PCI gen2 Express* x8 w/ x16 connector.
One riser slot supporting PCI Express* x8 riser cards PCI gen2 Express* x4 w/ x8
connector.
Two Intel
®
I/O Expansion Module card connectors supporting double- and single-
wide I/O modules.
Video Onboard ServerEngines* LLC Pilot II Controller
Matrox* G200 2D Video Graphics controller
Uses 8 MB of the BMC 32 MB DDR2 Memory
Hard Drive Support for six ICH10R SATA II ports
Optional support for SW RAID 5 with activation key
LAN Two 10/100/1000 ports provided by Intel
®
82576
Server Management Onboard ServerEngines* LLC Pilot II Controller.
Integrated Baseboard Management Controller (Integrated BMC), IPMI 2.0 compliant
Basic
• BMC Controller: ARC 926E-S microcontroller
• Super IO: Serial Port logic, legacy interfaces, LPC interface, Port80
• Hardware Monitoring: Fan speed control and voltage monitoring
Advanced
• Video and USB compression and redirection
• NC-SI port, a high-speed sideband management interface
• Integrated Super I/O on LPC interface
