38 Intel Server Board SCB2 Product Guide
Installing and Removing a Terminator
If you are installing only one processor, you must install a terminator in the secondary processor
socket (A).
1. Observe the safety and ESD precautions at the beginning of this chapter and the additional
cautions given here.
2. Raise the locking bar on the socket.
3. To install a terminator, align the two corner marks on the terminator with the handle-side of the
socket (C) and then insert the terminator into the socket.
4. To remove a terminator, pull it out of the socket and then replace the it with another terminator
or install a processor.
5. Lower the locking bar (B) completely.
OM11710
A
B
D
C
Figure 22. Installing a Terminator
