52 Intel Server Board SCB2 Product Guide
Boot Menu
Feature Choices Description
Quiet Boot Disabled
Enabled
Disabled, displays normal POST messages.
Enabled, displays OEM Logo instead of POST
messages. Enabling this option disables serial
redirection.
Boot Device Priority Press <Enter> Enters submenu.
Hard Drive Press <Enter> Enters submenu.
Removable Devices Press <Enter> Enters submenu.
ATAPI CDROM Drives Press <Enter> Enters submenu.
Boot Device Priority Submenu
Use the up- or down-arrow keys to select a device. Press the <+> or <-> keys to move the device
higher or lower in the boot priority list.
Boot Priority Device Description
1
st
Boot Device Removable Devices Attempts to boot from a removable media device.
2
nd
Boot Device Hard Drive Attempts to boot from a hard drive device.
3
rd
Boot Device ATAPI CD-ROM Drive Attempts to boot from an ATAPI CD-ROM drive.
4
th
Boot Device Intel Boot Agent
version 4
Attempts to boot from a network when a network device
controlled by a PXE compliant ROM is present in the system.
Hard Disk Submenu
For options on this menu, use the up or down arrow keys to select a device. Press the <+> or <->
keys to move the device higher or lower in the boot priority list.
Option Description
1. Drive #1 (or actual drive string)
2. Other bootable cards
(additional entries for each drive that
has a PnP header)
Other bootable cards cover all the boot devices not reported to
the system BIOS through BIOS Boot Specification
mechanisms. It may or may not be bootable, and may not
correspond to any device.
Removable Devices Submenu
For options on this menu, use the up or down arrow keys to select a device.
Feature Option Description
Lists Bootable Removable devices in
the system.
Select one of the
detected devices
This list includes legacy 1.44-MB floppy
drives and 120-MB floppy drives.
