48 Intel Server Board SCB2 Product Guide
Onboard Video Submenu
Feature Choices Description
Onboard Video Enabled
Disabled
Enables the embedded video controller.
Peripheral Configuration Submenu
Feature Choices Description
Serial Port 1 Address Disabled
3F8
2F8
3E8
2E8
Used to configure the serial port address. If console
redirection is used, verify that the I/O and IRQ are
identical to values configured in the “Server Setup”
menu.
Serial Port 1 IRQ 4
3
Used to configure the interrupt for serial port 1.
Serial Port 2 Address Disabled
3F8
2F8
3E8
2E8
Used to configure the serial port address. If console
redirection is used, verify that the I/O and IRQ are
identical to values configured in the “Server Setup”
menu.
Serial Port 2 IRQ 4
3
Used to configure the interrupt for serial port 2.
Diskette Controller Enabled
Disabled
Used to enable or disable the onboard floppy disk
controller.
Legacy USB Support Disabled
Keyboard Only
Auto
Keyboard & Mouse
Enables support for legacy USB.
Front Panel USB Disabled
Enabled
Used to enable the USB ports accessed through the
internal USB header found on the baseboard.
Memory Configuration Submenu
Feature Choices Description
Extended Memory Test 1 MB
1 KB
Every Location
Disabled
Extended memory test options run during POST.
Note: the smaller the increment, the longer the test
takes during POST.
Bank #1 N/A Informational screen used to display whether DIMMs
are present in bank #1
Bank #2 N/A Informational screen used to display whether DIMMs
are present in bank #2
Bank #3 N/A Informational screen used to display whether DIMMs
are present in bank #3
Memory Retest Disabled
Enabled
If enabled, BIOS will activate and retest all DIMMs on
the next system boot. This option will be automatically
reset to disabled on the next system boot.
