41
4 Configuration Software and Utilities
Service Partition (Optional)
When you are setting up your server system, you can install a service partition onto your hard drive.
The service partition includes utilities, and other software that be run locally or remotely to assist in
system management. The service partition uses approximately 30 to 40 MB of hard disk space.
✏
NOTE
It is highly recommended that you install the service partition before
installing an operating system. For more information, see the Service
Partition section in the Installation Guide for the Intel Server Control. This
document is included on the Resource CD-ROM shipped with your SCB2
server board.
Configuration Utilities
System Software Update Sequence
When you update the system software, you should do it in the following order.
1. Update BIOS
2. Update firmware (BMC & HSC)
3. Update FRU/SDR
4. Unplug system for 30 seconds
5. Clear CMOS via front panel
