Configuration Software and Utilities 47
PCI Configuration Submenu
Feature Choices Description
USB Function Press <Enter> Enters Submenu
Onboard NIC 1 Press <Enter> Enters Submenu
Onboard NIC 2 Press <Enter> Enters Submenu
Onboard SCSI Press <Enter> Enters Submenu (SCSI model only)
Onboard R-IDE Press <Enter> Enters Submenu (ATA model only)
Onboard Video Press <Enter> Enters Submenu
Riser Card
Override
Enabled
Disabled
This option will only be displayed if a non-Intel chassis is used.
If enabled, all six options for PCI slots will be displayed
If disabled, only two options for PCI slots will be displayed
PCI Slot 1B
ROM
Enabled
Disabled
Used to enable or disable an option ROM that may be present on a
PCI add-in card installed in the slot.
In a 2U chassis, options for additional PCI slots PCI bus B will be
displayed
PCI Slot 1C
ROM
Enabled
Disabled
Used to enable or disable an option ROM that may be present on a
PCI add-in card installed in the slot
In a 2U chassis, options for additional PCI slots PCI bus C will be
displayed
USB Function Submenu
Feature Choices Description
USB Function Enabled
Disabled
Enables the embedded USB controller.
Onboard NIC1 and 2 Submenu
Feature Choices Description
Onboard NIC Enabled
Disabled
If enabled, the system uses the embedded NIC.
Embedded NIC ROM Enabled
Disabled
Enables the device option ROM.
Onboard SCSI Submenu
Feature Choices Description
Onboard SCSI Enabled
Disabled
Enables or disables embedded legacy SCSI controller
hardware.
Embedded LVD SCSI ROM Enabled
Disabled
Enables the device expansion ROM
Onboard R-IDE Submenu
Feature Choices Description
Onboard R-IDE Enabled
Disabled
If disabled, the embedded R-IDE device is turned off and
the device resources are hidden from the system
Onboard R-IDE ROM Enabled
Disabled
If enabled, initializes the embedded R-IDE device
expansion ROM
