37
Brackets
Screws
2. Four brackets secure the base unit to the pallet. Remove the two upper screws from each bracket
as shown in the previous figure.
3. Insert tinnerman nuts in holes 27 and 55 on both front mounting rails.
4. Extend the base unit rails in the rack until they lock. Refer to the following figure.
