70
Standard Board Placement
InterServe 650, 660
Slot
RAID Controller (CINF917) PCI 7
100 Base-T Fast Ethernet (CINF920) PCI 2
InterSite Server Monitor (CINF029) ISA 4
StudioZ RAX
Slot
RAID Controller (CINF917) PCI 7
RAID Controller (CINF917) PCI 6
RealiZm Z10T (MESAM96) PCI 5 and 4
StudioZ (MSMT297) PCI 3
100 base-T Fast Ethernet (CINF920) PCI 2
NOTE In StudioZ RAX, the RAID controller in PCI slot 6 connects to the InterRAID-8 cabinet.
Jumper Connectors
Connector
Jumper Result
J19 On
Off
Clears Real Time Clock and CMOS data
Default
J20 On
Off
Clears the BIOS Password
Default
J25 On
Off
Disables VGA display mode
Enables VGA display mode (default)
Cable Routing and Pinouts
From
Cable To
J26, SCSI MCBL102A CDSK094 and CDSK132
J27, ISA Bus (PCMCIA) MCBL084A MESAM86, J6
J28, ISA Bus (PCMCIA) MCBL084A MESAM86, J3
J29, Floppy MCBL106A MESAM86, J2
J30, speaker MCBLW660 Speaker
NOTE CDSK094 (2 GB fixed disk drive) is used only in StudioZ RAX.
