Intergraph StudioZ RAX - Page 81

71
J26, MCBL102A, SCSI
Pin
Signal Pin Signal Pin Signal
26 CD0 33 CD7 46 MSG
27 CD1 34 CD Parity 47 SCT
28 CD2 38 TPWR 48 CMD
29 CD3 41 ATTN 49 REQ
30 CD4 43 BSY 50 I/O
31 CD5 44 ACK Remaining Ground
32 CD6 45 RST
J27, MCBL084A, PCMCIA ISA Bus
Pin
Signal Pin Signal Pin Signal
1 IRQ15 15 SD+(0) 28 Ground
2 IRQ14 16 SD+(1) 29 RSTDRV
3 IRQ10 17 SD+(4) 30 Ground
4 IRQ3 18 SD+(5) 31 SA+(6)
5 IRQ7 19 MEMW- 32 SA+(7)
6 IRQ9 20 MEMR- 33 SA+(10)
7 IOCS16- 21 SA+(17) 34 SA+(11)
8 Ground 22 SA+(18) 35 SA+(14)
9 IOCHRDY+ 23 SA+(21) 36 SA+(15)
10 Ground 24 SA+(22) 37 BALE
11 SD+(14) 25 SA+(1) 38 IOR-
12 SD+(15) 26 Ground 39 D7BUFDIR
13 SD+(11) 27 SA+(3) 40 PWR
_
DWN
14 SD+(10)
J28, MCBL084A, PCMCIA ISA Bus
Pin
Signal Pin Signal Pin Signal
1 Spare 15 SD+(2) 28 Ground
2 IRQ11 16 SD+(3) 29 SA+(4)
3 IRQ4 17 SD+(6) 30 SA+(5)
4 IRQ5 18 SD+(7) 31 SA+(8)
5 0WS- 19 SA+(19) 32 SA+(9)
6 Ground 20 SA+(20) 33 SA+(12)
7 MEMCS16- 21 SA+(23) 34 SA+(13)
8 Ground 22 SBHE- 35 SA+(16)
9 SPKR- 23 SA+(0) 36 AEN
10 Ground 24 Ground 37 IOW-
11 SD+(13) 25 SA+(2) 38 Ground
Pin Signal
Pin Signal Pin Signal
