146 xGen Lite Installation and Programming Guide
2. Select Event Type and the Area.
3. Select the Schedule that will determine when this Scene is active.
4. Now program the sequence of actions that you want to happen.
Example
When Exit Delay 1 is running in the Office Area, set Camera 1 to start recording.
Programming Instructions for Outputs
Goal
Turn an output on or off according to an Action.
Event 1
and
or
Event 2
and
or
Event 3
and
or
Event 4
=
Action
State
+
Action
Result
Pre-conditions
Program the Action and any associated components.
Notes
See xGenLite Reference Guide for more details on Actions.
Write/Plan out on paper what you want to create. This makes it easier to set up
Actions and associated settings.
Actions can be used without programming an Action Result. For example,
outputs on xGenLite are controlled by monitoring an Action State, no Action
Result needs to be programmed.
Programming Sequence
8. Actions
7. Schedules
10. Devices
Outputs
zone expanders,
keypads, transmitters
14. Holidays
11. Permissions
7. Schedules
Instructions
1. Select the Device that has the physical outputs you want to control.
2. Select Outputs.
3. Select Action.
4. Select the Schedule.
