6 xGen Lite Installation and Programming Guide
Product
Main description
Current Consumption
(non-alarm)
Current
Consumption (alarm)
NXG-208-G3
8 zone expander
25 mA
25 mA
NXG-220-G3
20 zone expander
30 mA
30 mA
NXG-504
4 relay output expander
20 mA idle
70 mA 4 relays on
20 mA idle
70 mA 4 relays on
NXG-510
10 relay output expander
20 mA idle
160 mA 10 relays on
20 mA idle
160 mA 10 relays on
Output Current Rating
Output
Total Max Output Current
35 VA
Transformer
40 VA
Transformer
55 VA
Transformer
Combined J2 BELL+, J2 AUX+ (Smoke),
and J7 AUX+ (Outputs)
Combined J2 POS (XR Bus), and J3 POS
(NX Bus)
1.0 A max at
13.8 VDC
1.2 A max at
13.8 VDC
1.4 A max at
13.8 VDC
Auxiliary Current and Battery Capacity
xGen Lite (EMEA)
Discharge
Time
Charge
Time
7.2 Ah
Battery
12 Ah
Battery
18 Ah Battery
Reference
12 h
72 h
470 mA
870 mA
1370 mA
EN 50131 Grade 1 and 2
12 h
24 h
170 mA
370 mA
620 mA
INCERT
Note: Main board quiescent current is not included in the table above.
Example for EN Grade 2
When using battery backup as specified for EN Grade 2 using a 7.2 Ah battery,
the maximum available auxiliary current is 470 mA.
Environmental
Operating temperature
−10 to +55°C
Humidity
95% non-condensing
IP protection grade
IP30
NXG-4, NXG-8 metal enclosure
EN 50131 Grade 2, Class II
NXG-9 polycarbonate enclosure
EN 50131 Grade 2, Class II
Alarm transmission class EN50136-2/EN 50131-10:
Onboard IP
SP4 & DP4
Cellular
SP4 & DP4
