xGen Lite Installation and Programming Guide 5
Onboard outputs:
NXG-4
4: bell, strobe, siren and power outputs
NXG-8, NXG-9
5: bell, strobe, siren and power outputs
Maximum output number
32
Maximum action number
32
Partitions:
NXG-4
4
NXG-8, NXG-9
8
Maximum keypad:
NXG-4
16
NXG-8, NXG-9
24
Maximum expander modules, incl keypads:
NXG-4
24
NXG-8, NXG-9
32
Non-volatile Memory
Event log capacity
1024
Data retention (log, program settings)
10 years
Ethernet Connection (IP only)
Supported standard
IEEE 802.3u
Speed
10BASE-T or 100BASE-TX
Duplex
Half-duplex and full-duplex
Cabling
FTP (foiled twisted pair) Cat 5e cable or better
xGenLite Bus
Type
4 wire RS485 bus
High common mode tolerance (25V)
Capacity
Up to 32 devices
Range
800m
Recommended Cable
Belden 7201A, 3107A or 9842, 2 pair twisted
shielded data cable or exact equivalent (see
“Cable Requirements” on page 18)
Current Consumption
Product
Main description
Current Consumption
(non-alarm)
Current
Consumption (alarm)
NXG-8, NXG-9
8 zone panel
130 mA typical
130 mA typical
NXG-4
4 zone panel
130 mA typical
130 mA typical
NXG-1820
Touchscreen keypad
100 mA typical, 40 mA in
idle mode
175 mA max with
sounder and screen on
max brightness
