Intermec EasyCoder PD41 Service Manual

Chapter 2 — Models and Options
EasyCoder PD41/PD42 Printer Service Manual 17
Peel-off (self-strip) Option with internal
rewinder
Firmware (Fingerprint)
Operating system Fingerprint v10.x.x Includes Direct Protocol
Smooth fonts TrueType and TrueDoc fonts
Resident scalable fonts 15
Character sets • 23 single-byte character sets standard.
• UTF-8 support as standard.
Resident bar codes 61
Firmware (IPL)
Operating system IPL v10.x.x
Smooth fonts TrueType and TrueDoc fonts
Resident scalable fonts 13 (+21 simulated bitmap)
Character sets • 23 single-byte character sets standard
• UTF-8 support as standard
Resident bar codes 31
Environment
Operating temperature +5°C to +40°C (+41°F to 104°F)
Storage temperature -20
°C to 70°C (-4°F to 122°F)
Operating humidity 20 to 80% non-condensing
Storage humidity 10 to 90% non-condensing
Media
Media width 25 to 118 mm (1 to 4.6 in)
Max 114 mm (4.5 in) with cutter
Media roll diameter 213 mm (8.4 in) max.
190 mm (7.5 in) with internal rewinder
Internal rewinder diameter Max 140 mm (5.51 in)
Media roll core diameter 38.1 to 76.2 mm (1.5 to 3 in)
Media thickness 60 μm to 250 μm (2.3 to 9.8 mils)
Transfer Ribbon
Material Wax, hybrid, or resin
Winding Ink on either inside or outside of roll
Ribbon width 30 to 110 mm (1.18 to 4.33 in)
Ribbon roll diameter (outer) 76 mm (2.99 in) equivalent to 450 m (1471 ft) of ribbon.
Inner core diameter 25.2 to 25.6 mm (1 in)
Sensors
Label gap/black mark/out of
media
Yes
Printhead lifted Yes
Label taken Yes
Ribbon end Yes
EasyCoder PD42 Printer (continued)

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
