INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-163-
Function
code
Name
Description
Default
Modify
digital potentiometer are valid.
1: Only control through the ∧/∨ key is
valid.
2: Only control through the digital
potentiometer is valid.
3: Controls through the ∧/∨ key and digital
potentiometer are invalid.
Tens place: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting methods
2: Invalid for multi-step speed running when
multi-step speed running has the priority
Hundreds place: Action selection for stop
0: Setting is valid.
1: Valid during running, cleared after stop
2: Valid during running, cleared after a stop
command is received
Thousands place: Integral function of the ∧/
∨ key and digital potentiometer
0: Enable the integral function
1: Disable the integral function
P08.43
LED keypad
digital
potentiometer
integral rate
0.01–10.00s
0.10s
○
P08.44
UP/DOWN
terminal control
setting
0x000–0x221
Ones place: Frequency setting selection
0: The setting made through UP/DOWN is
valid.
1: The setting made through UP/DOWN is
invalid.
Tens place: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting methods
2: Invalid for multi-step speed running when
multi-step speed running has the priority
Hundreds place: Action selection for stop
0: Setting is valid.
0x000
○
