INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-60-
Function
code
Name
Description
Default
11: PLC
12: Reserved
Note: For setting methods 1–11, 100% corresponds to
the maximum frequency.
P03.15
Setting source of
reverse rotation
upper-limit
frequency in torque
control
0: Keypad (P03.17)
1–11: the same as P03.14
0
P03.16
Forward rotation
upper-limit
frequency set
through keypad in
torque control
0.00Hz–P00.03(Max. output frequency)
50.00 Hz
P03.17
Reverse rotation
upper-limit
frequency set
through keypad in
torque control
0.00Hz–P00.03(Max. output frequency)
50.00 Hz
P03.18
Setting source of
electromotive
torque upper limit
0: Keypad (P03.20)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus communication
6: PROFIBUS/CANopen/DeviceNet communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFINET communication
10: PLC
11: Reserved
Note: For setting sources 1–4 and 8, 100%
corresponds to three times the rated motor current.
0
P03.19
Setting source of
braking torque
upper limit
0: Keypad (P03.21)
1–10: Same as those for P03.18
0
P03.20
Electromotive
torque upper limit
set through keypad
0.0–300.0% (of the motor rated current)
180.0%
