INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-59-
Function
code
Name
Description
Default
P00.00
Speed control
mode
0: Sensorless vector control (SVC) mode 0
1: Sensorless vector control (SVC) mode 1
2: Space voltage vector control mode
3: Closed-loop vector control mode
Note: If 0, 1 or 3 is selected, it is required to carry out
motor parameter autotuning first.
2
P03.32
Enabling torque
control
0: Disable
1: Enable
0
P03.11
Torque setting
method
0: Keypad (P03.12)
1: Keypad (P03.12)
2: AI1
3: AI2
4: AI3
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus communication
8: PROFIBUS/CANopen/DeviceNet communication
9: Ethernet communication
10: Pulse frequency HDIB
11: EtherCAT/PROFINET communication
12: PLC
Note: For setting sources 2–6 and 10, 100%
corresponds to three times the rated motor current.
0
P03.12
Torque set through
keypad
-300.0%–300.0% (of the motor rated current)
50.0%
P03.13
Torque reference
filter time
0.000–10.000s
0.010s
P03.14
Setting source of
forward rotation
upper-limit
frequency in torque
control
0: Keypad (P03.16)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus communication
7: Profibus/CANopen/DeviceNet communication
8: Ethernet communication
9: Pulse frequency HDIB
10: EtherCat/Profinet communication
0
