IPE300 series engineering VFD Basic operation guidelines
-74-
Function
code
Name
Description
Default
8: Modbus communication
9: PROFIBUS/CANopen/DeviceNET
communication
10: Ethernet communication
11: High-speed pulse HDIB
12: Pulse train AB
13: EtherCat/Profinet communication
14: PLC
15: Reserved
P00.08
Reference object of B
frequency command
0: Max. output frequency
1: A frequency command
0
P00.09
Combination mode of setting
source
0: A
1: B
2: (A+B)
3: (A-B)
4: Max(A, B)
5: Min(A, B)
0
P05.01–P
05.06
Function selection of
multifunction digital input
terminals (S1–S4, HDIA,
HDIB)
10: Increase frequency setting (UP)
11: Decrease frequency setting (DOWN)
12: Clear the frequency increase/decrease
setting
13: Switch between A setting and B setting
14: Switch between combination setting
and A setting
15: Switch between combination setting
and B setting
P08.42
LED keypad digit control
setting
0x000–0x1223
Ones place: Frequency control enabling
selection
0: Controls through both the ∧/∨ key
and digital potentiometer are valid.
1: Only control through the ∧/∨ key is
valid.
2: Only control through the digital
potentiometer is valid.
3: Controls through the ∧/∨ key and
digital potentiometer are invalid.
Tens place: Frequency control selection
0000
