INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-75-
Function
code
Name
Description
Default
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting methods
2: Invalid for multi-step speed running
when multi-step speed running has the
priority
Hundreds place: Action selection for stop
0: Setting is valid.
1: Valid during running, cleared after stop
2: Valid during running, cleared after a stop
command is received
Thousands place: Integral function of the
∧/∨ key and digital potentiometer
0: Enable the integral function
1: Disable the integral function
P08.43
LED keypad digital
potentiometer integral rate
0.01–10.00s
0.10s
P08.44
UP/DOWN terminal control
setting
0x000–0x221
Ones place: Frequency setting selection
0: The setting made through UP/DOWN is
valid.
1: The setting made through UP/DOWN is
invalid.
Tens place: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting methods
2: Invalid for multi-step speed running
when multi-step speed running has the
priority
Hundreds place: Action selection for stop
0: Setting is valid.
1: Valid during running, cleared after stop
2: Valid during running, cleared after a stop
command is received
0x000
P08.45
Frequency increment change
rate of the UP terminal
0.01–50.00Hz/s
0.50 Hz/s
P08.46
Frequency reduce rate of the
DOWN terminal
0.01–50.00Hz/s
0.50 Hz/s
P17.00
Set frequency
0.00Hz–P00.03(Max. output frequency)
0.00Hz
