Wireless Access Point
User Guide
Setting up a WiFi network encrypted by WPA-PSK or WPA2-PSK
Networking requirement
WiFi network at home with a certain level of security must be configured through a simply procedure. In
this case, WPA-PSK or WPA2-PSK mode is recommended. See the following figure.
Procedures:
Assume that the second SSID of the AP, the WPA2-PSK security mode, and AES encryption algorithm are
used.
1. Choose Wireless > Basic.
2. Select the second SSID from the SSID drop-down list box, which is IP-COM_888889 in this example.
3. Tick the Enable box.
4. Set the value of the SSID box to Home.
5. Security Mode: Select WPA2-PSK.
6. Encryption Algorithm: Select AES.
7. Key: Enter 87654321.
8. Click Save.
